Multi Span Greenhouse
Created with Pixso.

Stable Structure Agricultural Multi Span Greenhouse 30-100m Length

Stable Structure Agricultural Multi Span Greenhouse 30-100m Length

Brand Name: sainpoly
MOQ: 500
Price: $6-10/sqm
Payment Terms: ,T/T
Supply Ability: 100000 hectare/year
Detail Information
Place of Origin:
Qingzhou city, Shandong Province, China
Certification:
CE certificate
Certificates:
CE
Covering Material:
Polycarbonate
Origin:
Shandong China
Length:
30-100m Or Customized Size
Side Height:
1.0m-1.5m
Entilation System:
Roof And Side Vents
Feature:
Stable Structure
Gutter Height:
3.5m-4.5m
Frame:
Hot-dipped Galvanized Frame
Foundation:
Concrete Or Steel Base
Advantages:
Low Cost,low Investment,fast Return
Heating System:
Optional
Packaging Details:
bulk/box
Highlight:

Stable Structure Multi Span Greenhouse

,

Multi Span Greenhouse 100m

,

Stable Structure Agricultural Greenhouse

Product Description

Low Cost Manufacturer Sale Agricultural Multi-span Film Greenhouses






Stable Structure Agricultural Multi Span Greenhouse 30-100m Length 0







Introduction



The Film Greenhouse is a versatile product category that offers an effective and economical solution for agricultural and horticultural cultivation.



This greenhouse features a covering made of high-quality polyethylene or other durable films, providing excellent light transmission, temperature regulation, and protection from external elements.



The film greenhouse comes in various sizes and configurations, catering to the needs of small-scale and large-scale growers alike.



Its lightweight and easy-to-install design make it a popular choice for extending growing seasons and creating optimal conditions for plants.



With its cost-effectiveness and practicality, the Film Greenhouse empowers growers to achieve higher yields and enhance productivity in their agricultural endeavors.



Different countries use different greenouse types, it's mainly according to local climate and temerature. We can recommend sutiable type for you.







Stable Structure Agricultural Multi Span Greenhouse 30-100m Length 1







Structure






Structure


Galvanized steel pipe


Zinc layer


275g/sqm


Span


8m-10m


Section


3m/4m/5m


Height


3-6m


Covering thickness


150 micro, 180 micron, 200 micro plastic film


Transmittance


More than 92%


Greenhouse size


Can be customized




Covering Material



Stable Structure Agricultural Multi Span Greenhouse 30-100m Length 2







Thickness: 150micro/200micro plastic film




Related systems:



  1. Cooling system

Stable Structure Agricultural Multi Span Greenhouse 30-100m Length 3





Exhaust fan has the galvanized housing, a large alunimum wheel, a 0.8mm frame, and a 0.4mm thick blind.



The cooling pad is made of polymer wet curtain paper, which is a special product that has been specially treated to

have high structural strength, currosion resistance, and excellent air permeability and water resistance.



The air enters the greenhouse through the cooling pad, which has the effect of cooling, moistening and dust removal.





2. Heating system



Heating system, refers to a set of suitable heating facilities selectred to meet heating needs, including heat source, heat dissipation facilities, and heat transfer facilities.



The main accessories include boilers, transmission pipelines, circulating water,

radiators, and various control or regulating valves.



Stable Structure Agricultural Multi Span Greenhouse 30-100m Length 4



3. Shading system



Inside shading: Installed in the greenhouse, fixed on the greenhouse structure and matched with the greenhouse frame.



Inside shading net: Made of white aluminum foil material and fixed by white support curtain wire.



Outside shading: Fixed on the outside roof frame, supported by columns and beams.



Outside shading net: Made of polyethylene, high-density polyethylene, PE, PB, PVC,

recycled materials, treated with UV stabilizers and anti-oxidation, with strong tensile strength, aging resistance, corrosion resistance, radiation resistance, lightness, etc, fixed with black support curtain wire.



Stable Structure Agricultural Multi Span Greenhouse 30-100m Length 5



4. Irrigation system:



Its working principle is to extract irrigation water from the source, pressurize, purify, filter appropriately, and then send it to the field irrigation facilities through the water pipeline.



Drip arrow: Used in combination with soilless cultivation. 3-4 drip arrows are placed per meter, and the planting spacing is 1.6m, excluding fertilizer applicators; including main pipeline, coonectors, PE pipe, drip arrow four-piece set, etc.



Drip Irrigation: mostly used for ground planting. The spacing of the drip irrigation belt is generally 0.8m, PE pipe. Including water pump, proportional fertilizer applicator, main pipeline, PE pipe, connectors, etc.





Stable Structure Agricultural Multi Span Greenhouse 30-100m Length 6  Stable Structure Agricultural Multi Span Greenhouse 30-100m Length 7





Except above systems, we can also offer fertilizer system, lighting system, hydroponic system,

rolling bench, climate control, LED grow lights, internal insulation system, etc.
